A multifunctional SMT machine, also known as a high-precision SMT machine or general-purpose machine, can mount high-precision large and irregular components. Generally, it can also mount small chip shaped components, covering almost all component ranges, so it is called a multifunctional SMT machine. Today, let's talk about the basic features of a multifunctional SMT machine:

　　1、 The structure of functional SMT machines mostly adopts an arch structure, which has the characteristics of high accuracy and good flexibility.

　　2、 In X and Y positioning systems, full closed-loop servo motors are mostly used for driving, and linear grating encoders are used for direct position feedback to avoid errors caused by screw distortion and deformation. Some use dual electric motors and dual screw rods on both sides of the platform in the y-axis, and use a bilinear grating ruler for feedback, which can effectively reduce the waiting caused by the stationary mounting head and reduce the error caused by asynchronous deformation of the crossbeam. There are more advanced linear magnetic levitation motors, which not only have the technical characteristics of dual drive, but also have the advantages of direct driving, less mechanical structure wear, fast feedback, quietness, easy maintenance, and high accuracy.

　　3、 Most multi kinetic energy SMT machines use fixed circuit boards and use the movement of the mounting head to achieve X and y positioning, without causing large or heavy components to shift due to inertia due to the movement of the tabletop.

　　4、 Able to accept all material packaging methods, such as tape packaging, tube packaging, box packaging, and disk packaging. In addition, when there are many materials in the tray, a multi-layer dedicated tray feeder can be added.

　　5、 In addition to using traditional vacuum suction nozzles for material absorption, specialized suction nozzles can also be used for components that are difficult to absorb with special shapes. In addition, pneumatic grippers can be used for components that cannot be absorbed with vacuum suction nozzles.

　　6、 When calibrating components, an overhead camera is generally used, which has functions such as front light, side light, backlight, and online light, and can recognize various different components. If the size of the component is too large, exceeding one view (FOV) of the camera, the upper view camera can also analyze and correct it through multiple views after taking photos. Some multifunctional SMT machines also have a mobile camera on the mounting head, which can identify various smaller components.
